| Model | HK-Z48/08-S1 |
| Operation control mode | Pressure start and stop |
| Rated pressure (MPa) | 0.8 |
| Maximum pressure ( MPa) | 1.0 |
| Air flow (M³/min) | 4.8 |
| Running speed ( R/min) | 3200 |
| Drive mode | Belt drive |
| Exhaust air temperature ( ºC ) | ≤ambient temperature + 15 ºC |
| Exhaust outlet diameter ( Inch ) | 1½ |
| Volume of the air tank ( L) | / |
| Noise dB(A) | 65±2 |
| Type of motor | Three-phase asynchronous motors |
| Motor rated output ( KW) | 44KW/66HP |
| Motor frequency ( HZ ) | 50 |
| Motor voltage ( V ) | 380 |
| Motor rated current ( A ) | / |
| Dimension (MM ) | 2320*1450*1740 |
| Weight ( KG ) | 1520 |
